Industrial Dispenser

AID

16, 24, 32...96 materials or more for customization
Apply to industry of paint & coatings, ink printing, auxiliary chemicals, food, leather, cosmetics, etc.

Send Inquiry

Features

parameters

Documents Download

It goes well with

inquiry

Features

Automatic dispensing

Adopt weighing feedback system with high precision, the accuracy is up to ±0.1g

Automatic formula reading

Automatic filling materials according to formulas, avoid mis-filling.

Connect with client's ERP/MES system directly

Automatic data feedback; Improved factory informatization; Accurate statistics of material consumption.

Match with spectrophotometer

Available data of color matching software for production .

Parameters

Efficiency	20kg/3min (3-4 kinds of materials)
Accuracy	30kg/1g（10kg/0.1g optional)
Air Source Pressure	0.6 Mpa
Weighing Scope	5kg、10kg、30kg…1000kg、1500kg、2000kg、3000kg
Power Supply	220V/110V 50Hz/60Hz

No. of Canisters	12、16、24、32…96(customizable)
Weighing Sensor	Mettler-Toledo/Flintec
Filling Valve	Three-section high accuracy valve
Diaphragm Pump	ARO
Industry	Paint & coatings, ink printing, auxiliary chemicals, food, leather, cosmetics, etc.
